Chapter 7 581
Language Reference
RL Reference/Range Level
Table 7-8 Frequency Ranges and Minimum Reference Level (0 dB Input
Attenuation)
Minimum Reference Level
Band Log Scale Linear Scale
8560E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
Agilent 8561E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
2.9 GHz to 6.5 GHz 120.0 dBm 2.2 µV
Agilent 8562E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz 120.0 dBm 2.2 µV
6.76 GHz to 13.2 GHz 120.0 dBm 2.2 µV
Agilent 8563E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz 120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz 120.0 dBm 2.2 µV
13.2 GHz to 26.5 GHz 120.0 dBm 2.2 µV
Agilent 8564E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz 120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz 120.0 dBm 2.2 µV
13.2 GHz to 26.8 GHz 120.0 dBm 2.2 µV
26.8 GHz to 31.15 GHz 120.0 dBm 3.98 µV
31.15 GHz to 40 GHz 115.0 dBm 3.98 µV
Agilent 8565E/EC:
30 Hz to 2.9 GHz 120.0 dBm 2.2 µV
2.9 GHz to 6.46 GHz 120.0 dBm 2.2 µV
6.46 GHz to 13.2 GHz 120.0 dBm 2.2 µV
13.2 GHz to 26.8 GHz 120.0 dBm 2.2 µV
26.8 GHz to 31.15 GHz 120.0 dBm 2.2 µV
31.15 GHz to 40 GHz 115.0 dBm 3.98 µV
40 GHz to 50 GHz 115.0 dBm 3.98 µV
