5-24
Hardkey/Softkey Reference
Analyzer Functions
a calibration standard type.
leads to the frequency offset menu (Option 089 only).
switches the frequency offset mode on and off.
specifies the frequency of a calibration factor or loss value
in the power meter cal loss/sensor lists.
selects an existing frequency band to be reviewed, edited,
or deleted. The maximum number of frequency bands is 12
(numbered 1 to 12).
blanks the displayed frequency notation for security
purposes. Frequency labels cannot be restored except by
instrument preset or turning the power off and then on.
sets the LO frequency to CW mode for frequency offset.
sets the LO frequency to sweep mode for frequency offset.
provides access to the series of menus used to perform a
complete calibration for measurement of all four
S-parameters of a two-port device. This is the most
accurate calibration for measurements of two-port devices.
(ES only)
measures the forward isolation of the calibration
standard.
(Label Class) lets you enter a label for the forward match class. The
label appears during a calibration that uses this class.
(Specify Class) specifies which standards are in the forward match class
in the calibration kit.
measures the forward match using a thru standard.
(Label Class) lets you enter a label for the forward transmission class.
The label appears during a calibration that uses this class.
(Specify Class) specifies which standards are in the forward transmission
class in the calibration kit.
measures the forward transmission frequency response in
a two-port calibration.
displays the complex admittance values of the active
marker in rectangular form. The active marker values are
displayed in terms of conductance (in Siemens),
susceptance, and equivalent capacitance or inductance.
Siemens are the international units of admittance, and are
equivalent to mhos (the inverse of Ωs). The Smith chart
graticule is changed to admittance form.
giga/nano (10
9
/ 10
−9
). Used to terminate numeric entries.
G/n
