5-25
Hardkey/Softkey Reference
Analyzer Functions
(Option 010 only) turns gating on or off in time domain
mode.
(Option 010 only) allows you to specify the time at the
center of the gate.
(Option 010 only) allows you to specify the gate periods.
(Option 010 only) allows you to specify the starting time of
the gate.
(Option 010 only) allows you to specify the stopping time of
the gate.
(Option 010 only) leads to the gate shape menu.
(Option 010 only) selects the widest time domain gate with
the smallest passband ripple.
(Option 010 only) selects the narrowest time domain gate
with the largest passband ripple.
(Option 010 only) selects an intermediate time domain
gate.
(Option 010 only) selects an intermediate time domain
gate.
copies the sequence titles currently in memory into the six
softkey positions.
calls sub-routines in sequencing.
toggles the GPIB diagnostic feature (debug mode). This
mode should only be used the first time a program is
written: if a program has already been debugged, it is
unnecessary.
When diagnostics are on, the analyzer scrolls a history of
incoming GPIB commands across the display in the title
line. Nonprintable characters are represented as pi. If a
syntax error is received, the commands halt and a pointer
wedge indicates the misunderstood character. For
information on clearing a syntax error, refer to the
programmer's guide.
sets the format of the graphic file when
is selected. The only graphic
selection currently available is the JPEG format.
specifies whether or not to store display graphics on disk
with the instrument state.
brings up the graticule print color definition menu. The
graticule default print color is cyan.
