Hardkey/Softkey Reference
Analyzer Functions
selects the display graticule for color modification.
(Option 002 only) leads to the harmonics menu. Measured
harmonics cannot exceed the frequency range of the
analyzer receiver.
(Option 002 only) turns off the harmonic measurement
mode.
(Option 002 only) selects measurement of the second
harmonic.
(Option 002 only) selects measurement of the third
harmonic.
provides an on-line quick reference guide to using the
adapter removal technique.
freezes the data trace on the display, and the analyzer
stops sweeping and taking data. The notation “Hld” is
displayed at the left of the graticule. If the * indicator is on
at the left side of the display, trigger a new sweep with
.
is used to select the bandwidth value for IF bandwidth
reduction. Allowed values (in Hz) are 6000, 3700, 3000,
1000, 300, 100, 30, and 10. Any other value will default to
the closest allowed value. A narrow bandwidth slows the
sweep speed but provides better signal-to-noise ratio. The
selected bandwidth value is shown in brackets in the
softkey label.
jumps to one of the six sequence positions (SEQUENCE 1
through 6) if the limit test fails. This command executes
any sequence residing in the selected position. Sequences
may jump to themselves as well as to any of the other
sequences in memory. When this softkey is pressed, the
analyzer presents a softkey menu showing the six
sequence positions and the titles of the sequences located
in them. Choose the destination sequence to be called if
the limit test fails.
jumps to one of the six sequence positions (SEQUENCE 1
through 6) if the limit test passes. This command executes
any sequence residing in the selected position. Sequences
may jump to themselves as well as to any of the other
sequences in memory. When this softkey is pressed, the
analyzer presents a softkey menu showing the six
sequence positions, and the titles of the sequences located
in them. Choose the sequence to be called if the limit test
passes (destination sequence).
