1-18
8753ES Specifications and Characteristics
Instrument Specifications
Table 1-16 Test Port Input
8753ES Test Port Input
Description Specification Supplemental Information
External Source Mode
a
Frequency Range at −25 dBm R channel power
level
Standard 300 kHz to 3 GHz
Option 006 300 kHz to 6 GHz
R Input Requirements
Power Level 0 to −25 dBm, typ.
R Input Spectral Purity
Requirement
Maximum Spurious Input < −30 dBc, typ.
Residual FM < 20 kHz, typ.
Settling Time
Auto 500 ms, typ.
Manual 50 ms, typ.
Frequency Readout Accuracy 0.1%, auto, typ.
Input Frequency Accuracy
Requirement
Manual −0.5 to 5 MHz, typ.
a. Measurement accuracy is dependent on the stability of the input signal.
