Agilent Technologies 8720ES Reference Guide

1-19
8753ES Specifications and Characteristics
Instrument Specifications
Table 1-17 Test Port Input
8753ES Test Port Input
Description Specification
System Bandwidths
3000 Hz 10 Hz
Trace Noise
a
a. Trace noise is defined for a transmission measurement in CW mode, using a
“through” cable having 0 dB loss, with the source set to +5 dBm, and no
averaging.
Magnitude
300 kHz to 3GHz < 0.006 dB rms < 0.001 dB rms
3 GHz to 6 GHz < 0.010 dB rms < 0.002 dB rms
Phase
300 kHz to 3GHz < 0.038° rms < 0.006° rms
3 GHz to 6 GHz < 0.070° rms < 0.012° rms
Table 1-18 Test Port Input
8753ES Test Port Input
Description Specification Supplemental
Information
Reference Level
Magnitude
Range ±500 dB
Resolution 0.001 dB
Phase
Range ±500°
Resolution 0.01°
