Agilent Technologies 89410A Service Guide

2-6
Adjusting the Analyzer
Remote Operation
Adjustments can be setup using the remote operation capability of the
Agilent 89410A analyzer. The following table lists the adjustments and
corresponding HPIB codes. See the Agilent 89400 Series HPIB
Command Reference for general information on remote operation.
Adjustment HPIB Code
Channel 1 Input flatness setup 1 DIAG:ADJ:INP1:FLAT 1
Channel 1 Input flatness setup 2 DIAG:ADJ:INP1:FLAT 2
Channel 1 Input flatness setup 3 DIAG:ADJ:INP1:FLAT 3
Channel 2 Input flatness setup 1 DIAG:ADJ:INP2:FLAT 1
Channel 2 Input flatness setup 2 DIAG:ADJ:INP2:FLAT 2
Channel 2 Input flatness setup 3 DIAG:ADJ:INP2:FLAT 3
Channel 1 Input capacitance setup 1 DIAG:ADJ:INP1:CAP 1
Channel 1 Input capacitance setup 2 DIAG:ADJ:INP1:CAP 2
Channel 2 Input capacitance setup 1 DIAG:ADJ:INP2:CAP 1
Channel 2 Input capacitance setup 2 DIAG:ADJ:INP2:CAP 2
Channel 1 Input offset DIAG:ADJ:INP1:FET 1
Channel 2 Input offset DIAG:ADJ:INP2:FET 1
Channel 1 Anti-alias filter setup 1 DIAG:ADJ:INP1:AAF 1
Channel 1 Anti-alias filter setup 2 DIAG:ADJ:INP1:AAF 2
Channel 1 Anti-alias filter setup 3 DIAG:ADJ:INP1:AAF 3
Channel 2 Anti-alias filter setup 1 DIAG:ADJ:INP2:AAF 1
Channel 2 Anti-alias filter setup 2 DIAG:ADJ:INP2:AAF 2
Channel 2 Anti-alias filter setup 3 DIAG:ADJ:INP2:AAF 3
ADC DIAG:ADJ:ADC:SDIT
10 MHz low pass filter setup 1 DIAG:ADJ:SOUR 1
10 MHz low pass filter setup 2 DIAG:ADJ:SOUR 2
Autorange detect level DIAG:MODE:TRIG:LEV 128
Display brightness DISP:BRIG 100 PCT
