Agilent 89410A Front Panel
1-A softkey’s function changes as different
menus are displayed. Its current function is
determined by the video label to its left, on the
analyzer’s screen.
2-The analyzer’s screen is divided into two
main areas. The menu area, a narrow column
at the screen’s right edge, displays softkey
labels. The data area, the remaining portion of
the screen, displays traces and other data.
3-The POWER switch turns the analyzer on
and off.
4-Use a 3.5-inch flexible disk (DS,HD) in this
disk drive to save your work.
5-The KEYBOARD connector allows you to
attach an optional keyboard to the analyzer.
The keyboard is most useful for writing and
editing Agilent Instrument BASIC programs.
6- The SOURCE connector routes the
analyzer’s source output to your DUT. Output
impedance is selectable: 50 ohms or 75 ohms.
7-The EXT TRIGGER connector lets you
provide an external trigger for the analyzer.
8-The PROBE POWER connectors provides
power for various Agilent active probes.
9-The CHANNEL 1 input connector routes
your test signal or DUT output to the analyzer’s
receiver. Input impedance is selectable: 50
ohms, 75 ohms, or 1 megohm.
10-Use the DISPLAY hardkeys and their
menus to select and manipulate trace data and
to select display options for that data.
11-Use the SYSTEM hardkeys and their
menus to control various system functions
(online help, plotting, presetting, and so on).
12-Use the MEASUREMENT hardkeys and
their menus to control the analyzer’s receiver
and source, and to specify other measurement
parameters.
13-The REMOTE OPERATION hardkey and
LED indicators allow you to set up and monitor
the activity of remote devices.
14-Use the MARKER hardkeys and their
menus to control marker positioning and
marker functions.
15-The knob’s primary purpose is to move a
marker along the trace. But you can also use it
to change values during numeric entry, move a
cursor during text entry, or select a hypertext
link in help topics.
16-Use the Marker/Entry key to determine the
knob’s function. With the Marker indicator
illuminated, the knob moves a marker along the
trace. With the Entry indicator illuminated, the
knob changes numeric entry values.
17-Use the ENTRY hardkeys to change the
value of numeric parameters or to enter
numeric characters in text strings.
18-The optional CHANNEL 2 input connector
routes your test signal or DUT output to the
analyzer’s receiver. Input impedance is
selectable: 50 ohms, 75 ohms, or 1 megohm.
For easy of upgrading, the CHANNEL 2 BNC
connector is installed even if option AY7
(second input channel) is not installed.
For more details on the Agilent
89410A front panel, display the
online help topic ‘’Front Panel.’’
