To connect the optional keyboard
The analyzer may be connected to an optional external keyboard. The
keyboard remains active even when the analyzer is not in alpha entry
mode. This means that you can operate the analyzer using the external
keyboard rather than the front panel. Pressing the appropriate keyboard
key does the same thing as pressing a hardkey or a softkey on the
analyzer’s front panel.
1 Set the power switch to on ( l ).
2 Connect the round plug on the keyboard cable to the KEYBOARD connector on
the analyzer’s front panel. Make sure to align the plug with the connector pins.
3 Connect the other end of the keyboard cable to the keyboard.
Preparing the Analyzer for Use Agilent 89410A
To connect the optional keyboard
1-14
