To run the program in semiautomated mode
You must have an GPIB printer connected to your system to run the
program in semiautomated mode. If you do not have a printer, see ‘’To run
the program without a printer’’ later in this chapter.
1 Press the following keys and when the program prompts you, type in the
information for the title page of the test record and press [
enter
]:
[
TITLE PAGE
]
[
TEST FACILITY
]
[
FACILITY ADDRESS
]
[
TESTED BY
]
[
REPORT NUMBER
]
[
CUSTOMER
]
[
MORE
]
[
TEMP
]
[
HUMIDITY
]
[
LINE FREQUENCY
]
[
RETURN
]
2 Press the following keys and when the program prompts you, type in the
equipment configuration information:
[
EQUIP CONFIG
]
[
SYNTHESIZER
]
[
SYNTH/ LVL GEN
]
[
ANALYZER
]
[
MULTIMETER
]
[
MORE
]
[
STEP_ATT 1DB
]
[
STEP_ATT 10DB
]
[
mW-POWER METER
]
[
RETURN
]
The GPIB address is 100
× (interface select code) + (primary address).
The interface select code for the test equipment and printer is 7 (for
example, if the primary address is 8, the GPIB address is 708).
When entering the calibration due date, only four characters are displayed
on the screen. However, you can enter up to nine characters and they
will be printed.
Verifying Specifications Agilent 89410A
To run the program in semiautomated mode
2-10
