To run the program in manual mode
Use this procedure if you want to run the program in manual mode. You
will be prompted to set up all test equipment and you can check the
analyzer’s setup state after each measurement.
1 Press the following keys and when the program prompts you, set all GPIB
addresses to 0:
[
EQUIP CONFIG
]
[
SYNTHESIZER
]
[
SYNTH/ LVL GEN
]
[
ANALYZER
]
[
MULTIMETER
]
[
MORE
]
[
STEP_ATT 1DB
]
[
STEP_ATT 10DB
]
[
mW-POWER METER
]
[
RETURN
]
2 Press the following keys:
[
TEST CONFIG
]
[
PROCEDURE
]
[
OP_VERIFY
]or[
PERFORMAN
]
[
STOP AFTER
]
[
EACH MEASUREMENT
]
[
RETURN
]
3 Press the following keys to start the test:
[
START TESTING
]
[
START BEGINNING
]
4 Now follow the directions on the display and record the measurement result in
the test record after every measurement.
If you want to view the analyzer’s setup state, press [
BASIC
][
View State
]
[
measurement state
]or[
input/source state
]. To continue the program, press
[
Display
][
BASIC display format
][
lower
][
BASIC
][
continue
]. If you changed any
instrument setup states, press [
RESTART TEST
] to ensure accurate
measurement results.
The directions on the display briefly tell you how to connect test
equipment. For detailed illustrations of equipment setup, see the setup
illustrations starting on the next page.
Agilent 89410A Verifying Specifications
To run the program in manual mode
2-13
