Agilent Technologies 89410A Installation And Verification

To set up the input capacitance test
Performance Test only
This test verifies that the Agilent 89410A meets its input specification for
impedance. In this test, capacitance is measured using a frequency
synthesizer and a 100 kΩ resistor. Capacitance is then calculated using the
following formula:
C(pf)=C_ factor
√
Vin
2
⁄
Vc
2
−1.21 × 1.0
12
Where C_factor = 1.59
-11
at 100 kHz
1
2
Verifying Specifications Agilent 89410A
To set up the input capacitance test
2-30
