Measurement Uncertainty
The following table lists the measurement uncertainty and ratio for each
performance test using the recommended test equipment. Except for the
Intermodulation Distortion performance test, the ratios listed for the
recommended test equipment meet or exceed the measurement uncertainty
ratio required by U.S. MIL-STD-45662A.
l If you are using equipment other than the recommended test equipment, you
may calculate and record the measurement uncertainty and ratio for each
performance test. The table may be reproduced without written permission of
Agilent Technologies.
Performance Test
Using Recommended Test Equipment Using Other Test Equipment
Measurement
Uncertainty
Ratio
Measurement
Uncertainty
Ratio
Self test NA NA
Frequency accuracy
±0.125027 Hz
>10:1
Amplitude accuracy
−30 dBm
±0.056 dB
>10:1
−18 dBm
±0.053 dB
>10:1
−6dBm
±0.047 dB
>10:1
6dBm
±0.053 dB
>10:1
18 dBm
±0.047 dB
>10:1
Amplitude linearity
−10 dB
±0.006 dB
>10:1
−20 dB
±0.006 dB
>10:1
−30 dB
±0.006 dB
>10:1
−40 dB
±0.006 dB
>10:1
−50 dB
±0.015 dB
10:1
−60 dB
±0.015 dB
>10:1
−70 dB
±0.015 dB
>10:1
Amp_phase match
magnitude 0.046 dB 5.4:1
phase 0.0052 degree >10:1
Intermodulation distortion
±3.3 dB
3.1:1 †
Input coupling NA NA
Input trigger NA NA
External trigger NA NA
External arm NA NA
NA (not applicable) internal test
† If measured value is within ±2 dB of specification, verify distortion products of the test signal.
Agilent 89410A Verifying Specifications
Measurement Uncertainty
2-51
