Table of Contents
1 Preparing the Analyzer
for Use
To do the incoming inspection 1-5
To install the analyzer 1-7
To change the line-voltage selector switch 1-8
To change the fuse 1-9
To connect the analyzer to a LAN 1-10
To connect the analyzer to a serial device 1-10
To connect the analyzer to a parallel device 1-11
To connect the analyzer to an GPIB device 1-11
To connect the analyzer to an external monitor 1-12
To connect an external frequency reference 1-12
To connect the optional frequency reference 1-13
To connect the optional keyboard 1-14
To clean the screen 1-16
To store the analyzer 1-16
To transport the analyzer 1-17
If the analyzer will not power up 1-18
2 Verifying Specifications
To load the program 2-9
To run the program in semiautomated mode 2-10
To run the program without a printer 2-12
Toruntheprograminmanualmode 2-13
To set up the self test 2-14
To set up the frequency accuracy test 2-15
To set up the amplitude accuracy test 2-16
To set up the amplitude linearity test 2-20
To set up the amp_phase match test 2-21
To set up the intermodulation distortion test 2-22
Tosetuptheinputcouplingtest2-24
To set up the input trigger test 2-25
xv
