Agilent Technologies 89410A Installation And Verification

To set up the source amplitude accuracy test
Performance Test and Operation Verification
This test verifies that the Agilent 89410A meets its source specification for
amplitude accuracy. In this test, the synthesizer/level generator is connected
to channel 1 and measurements are made at eleven amplitudes and eight
frequencies (the ‘’Performance Test Record’’ at the end of this chapter lists
the amplitudes and frequencies). The 89410A’s source is then connected to
channel 1 and the signal level is measured and compared to the level from the
synthesizer/level generator.
1
2
Agilent 89410A Verifying Specifications
To set up the source amplitude accuracy test
2-39
