Agilent Technologies 89410A Installation And Verification

To set up the external trigger test
Performance Test and Operation Verification
This test verifies that the Agilent 89410A meets its trigger specification for
external trigger. In this test, a signal is connected to the external trigger
input and channel 1. Trigger level and slope are then verified by reading the
signal level and slope at 0 seconds in the time record.
1
Verifying Specifications Agilent 89410A
To set up the external trigger test
2-26
