To set up the cross talk test
Performance Test only
This test verifies that the Agilent 89410A meets its dynamic range
specification for channel-to-channel and source-to-input cross talk. In this
test, the 89410A measures the amount of energy induced from the source or
input channel to another input channel. For source-to-receiver crosstalk, the
analyzer’s source is turned on and set for a high level output, then the signal
level at the input is measured. For channel-to-channel crosstalk, a
9.9876 MHz, +20 dBm signal is connected to one channel and the signal level
at the other input channel is measured.
1
2
Option AY7 only
