Agilent Technologies 89410A Installation And Verification

Input Rtn Loss
Measurement Lower Limit Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
Channel 1, 50 ohm, −20 dBm
−25
Channel 1, 50 ohm, −22 dBm
−25
Channel 2, 50 ohm, −20 dBm †
−25
Channel 2, 50 ohm, −22 dBm †
−25
Channel 1, 75 ohm, −20 dBm
−20
Channel 1, 75 ohm, −22 dBm
−20
Channel 2, 75 ohm, −20 dBm †
−20
Channel 2, 75 ohm, −22 dBm †
−20
† Option AY7 only
Source Rtn Loss
Measurement Lower Limit Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
50 ohm, 0 dB Attenuator
−20
50 ohm, 10 dB Attenuator
−20
50 ohm, 20 dB Attenuator
−20
50 ohm, 40 dB Attenuator
−20
75 ohm, 0 dB Attenuator
−20
75 ohm, 10 dB Attenuator
−20
75 ohm, 20 dB Attenuator
−20
75 ohm, 40 dB Attenuator
−20
Serial Number:______________________Report Number:____________________
Agilent 89410A Verifying Specifications
Performance Test Record
13 of 14
