11 4 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:DIST:CLOS
:CALC{1-4}:TRAN:DIST:CLOS
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:CLOSs <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:CLOSs?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the cable loss
value used for the transformation function of the fault location function.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:DIST:CLOS 10"
20 OUTPUT 717;":CALC1:TRAN:DIST:CLOS?"
30 ENTER 717;A
Related commands :CALC{1-4}:TRAN:TIME:CLOS on page 129
:CALC{1-4}:TRAN:DIST:UNIT on page 125
:CALC{1-4}:TRAN:METH on page 126
Equivalent key [Analysis] - Fault Location - Cable Loss
<numeric>
Description Cable Loss value
Range Varies depending on the distance unit.
Preset value 0
Unit dB/100Ft or dB/100m
