11 8 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:DIST:REFL:TYPE
:CALC{1-4}:TRAN:DIST:REFL:TYPE
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:REFLection:TYPE
{OWAY|RTRip}
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:DISTance:REFLection:TYPE?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), selects the reflection
distance either one way or round trip.
Parameters
Query response {OWAY|RTR}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:DIST:REFL:TYPE RTR"
20 OUTPUT 717;":CALC1:TRAN:DIST:REFL:TYPE?"
30 ENTER 717;A$
Related commands :CALC{1-4}:TRAN:TIME:REFL:TYPE on page 133
Equivalent key [Analysis] - Fault Location - Reflection Type (One Way|Round Trip)
Description
OWAY Specifies the one way.
RTRip (preset value) Specifies the round trip.
