130 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:TIME:IMP:WIDT
:CALC{1-4}:TRAN:TIME:IMP:WIDT
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:IMPulse:WIDTh <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:IMPulse:WIDTh?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the shape of the
Kayser Bessel window using the impulse width used for the transformation function of the
fault location function.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:TIME:IMP:WIDT 1E-10"
20 OUTPUT 717;":CALC1:TRAN:TIME:IMP:WIDT?"
30 ENTER 717;A
Related commands :CALC{1-4}:TRAN:TIME:KBES on page 131
:CALC{1-4}:TRAN:TIME:STEP:RTIM on page 137
:CALC{1-4}:TRAN:TIME:STAT on page 136
:CALC{1-4}:TRAN:DIST:IMP:WIDT on page 115
Equivalent key [Analysis] - Fault Location - Window - Impulse Width
<numeric>
Description Impulse width
Range Varies depending on the frequency span and the transformation
type.
Preset value Varies depending on the frequency span and the transformation
type.
Unit s (second)
