:CALC{1-4}:TRAN:TIME:STEP:RTIM
:CALC{1-4}:TRAN:TIME:STEP:RTIM
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:STEP:RTIMe <numeric>
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:STEP:RTIMe?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the shape of the
Kayser Bessel window using the rise time of step signal used for the transformation
function of the fault location function.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:TIME:STEP:RTIM 1E-10"
20 OUTPUT 717;":CALC1:TRAN:TIME:STEP:RTIM?"
30 ENTER 717;A
Related commands :CALC{1-4}:TRAN:TIME:IMP:WIDT on page 130
:CALC{1-4}:TRAN:TIME:KBES on page 131
:CALC{1-4}:TRAN:TIME:STAT on page 136
:CALC{1-4}:TRAN:DIST:STEP:RTIM on page 122
Equivalent key [Analysis] - Fault Location - Window - Step Rise
<numeric>
Description The rise time of step signal
Range Varies depending on the frequency span.
Preset value Varies depending on the frequency span.
Unit s (second)
