138 Appendix B
SCPI Command Reference
:CALC{1-4}:TRAN:TIME:STIM
:CALC{1-4}:TRAN:TIME:STIM
Syntax :CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:STIMulus {IMPulse|STEP}
:CALCulate{[1]|2|3|4}[:SELected]:TRANsform:TIME:STIMulus?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), selects the stimulus
type used for the transformation function of the fault location function.
Parameters
Query response {IMP|STEP}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:TRAN:TIME LPAS"
20 OUTPUT 717;":CALC1:TRAN:TIME:STIM STEP"
30 OUTPUT 717;":CALC1:TRAN:TIME:STIM?"
40 ENTER 717;A$
Related commands :CALC{1-4}:TRAN:TIME on page 127
:CALC{1-4}:TRAN:TIME:STAT on page 136
:CALC{1-4}:TRAN:DIST:STIM on page 123
Equivalent key [Analysis] - Fault Location - Type - Bandpass|Lowpass Step|Lowpass Imp.
NOTE When performing this operation from the front panel, you select the transformation type at
the same time.
Description
IMPulse (preset value)
Specifies the impulse
*1
.
STEP
Specifies the step
*2
.
*1.You need to select the transformation type (band-pass or low-pass) with the
:CALC{1-4}:TRAN:TIME command.
*2.You do not need to select the transformation type. Low-pass is selected automatically.
