146 Appendix B
SCPI Command Reference
:CALC{1-4}:SRL:CONN{1-2}:LENG
:CALC{1-4}:SRL:CONN{1-2}:LENG
Syntax :CALCulate{[1]|2|3|4}:SRL:CONNector{[1]|2}:LENGth <numeric>
:CALCulate{[1]|2|3|4}:SRL:CONNector{[1]|2}:LENGth?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the connector
length value for the connector mismatch compensation.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:SRL:CONN1:LENG 0.01"
20 OUTPUT 717;":CALC1:SRL:CONN1:LENG?"
30 ENTER 717;A
Related commands :CALC{1-4}:TRAN:DIST on page 112
:CALC{1-4}:SRL:CONN{1-2}:IMM on page 145
:CALC{1-4}:SRL:CONN{1-2}:IMP? on page 145
Equivalent key [Analysis] - SRL - Portx Connector - Length
<numeric>
Description Cable length value
Range -0.02 to 0.2
Preset value 0
Unit m (meters)
