148 Appendix B
SCPI Command Reference
:CALC{1-4}:SRL:IMP:AUTO:CUT
:CALC{1-4}:SRL:IMP:AUTO:CUT
Syntax :CALCulate{[1]|2|3|4}:SRL:IMPedance:AUTO:CUToff <numeric>
:CALCulate{[1]|2|3|4}:SRL:IMPedance:AUTO:CUToff?
Description For the active trace of channel 1 (:CALC1) to channel 4 (:CALC4), sets the cutoff
frequency for the auto calculation for the average cable impedance.
Parameters
If the specified parameter is out of the allowable setup range, the minimum value (if the
lower limit of the range is not reached) or the maximum value (if the upper limit of the
range is exceeded) is set.
Query response {numeric}<newline><^END>
Example of use 10 OUTPUT 717;":CALC1:SRL:IMP:AUTO:CUT 2.0e+008"
20 OUTPUT 717;":CALC1:SRL:IMP:AUTO:CUT?"
30 ENTER 717;A
Related commands :CALC{1-4}:SRL:IMP:AUTO on page 147
:CALC{1-4}:SRL:IMP:MAN on page 149
Equivalent key [Analysis] - SRL - Z Cutoff Freq
<numeric>
Description Maximum frequency value
Range 300000 to 3e+009
Preset value 2.1e+008
Unit Hz
