6-27

Error Messages

ESG-D Series Signal Generator Instrument-Specific Error Messages

for FM1/PM1. This error will be reported to the queue when FM1/PM1 is enabled and

FM2/PM2 is also enabled and an adjustment to either FM2/PM2 deviation causes the

FM2 or PM2 deviation to be greater than the FM1 or PM1 deviation. It will also be

reported when FM2/PM2 is being turned on, and the last FM1/PM1 deviation setting is

less than the current FM2/PM2 deviation setting. In both cases the FM1/PM1 deviation

will be adjusted to match the FM2/PM2 deviation.

Settings conflict;FM1/PM1 value set less than FM2/PM2 value. FM2/

PM2 changed to match FM1/PM1 value.

The deviation of FM2/PM2 must always be less than or equal to the deviation settings

for FM1/PM1. This error will be reported to the queue when FM2/PM2 is enabled and

FM1/PM1 is also enabled and an adjustment to either FM1/PM1 deviation causes the

FM1 or PM1 deviation to be less than the FM2 or PM2 deviation. It will also be reported

when FM1/PM1 is being turned on, and the last FM2/PM2 deviation setting is greater

than the current FM1/PM1 deviation setting. In both cases the FM2/PM2 deviation will

be adjusted to match the FM1/PM1 deviation.

Settings conflict;Enabled mod source conflicts with previously

enabled mod source. Previous mod disabled.

The signal generator has three sources: INT, EXT1, and EXT2 that are shared by the

FM1/PM1, AM1/AM2, FM2/PM2, pulse (INT and EXT2), and burst envelope (EXT1

only). Each source can only be used by one of the modulations at a time. If a source is

being used by an active modulation, and a request for the source is made by another

modulation, the first modulation will be turned off, the second modulation will be turned

on.

Settings conflict;External burst cannot be on while using AM.

Indicates that there is a hardware conflict for the burst envelope using the EXT1 source

(I/Q menu) and AM1/AM2. The most recently requested modulation will be turned on,

the previous modulation will be turned off.

Settings conflict;FM & PM not allowed.

Indicates that there is a hardware conflict between FM and PM. The most recently

requested modulation will be turned on, the previous modulation will be turned off.

Settings conflict;Pulse modulation cannot be on with internal

burst.

Indicates that there is a hardware conflict between pulse modulation and internal burst.

The most recently requested modulation will be turned on, the previous modulation will

be turned off.
