AIREDALE EasiCool - Page 142

EasiCool Precision Air Conditioning
0
100
200
300
400
500
600
0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70
Static Pressure [Pa]
Air Volume [m
3
/s]
DF13 - 17 EC Backward Fan Curve
DF13
DF15
DF17
0
100
200
300
400
500
600
700
800
900
1000
1100
1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90 2.00 2.10 2.20 2.30 2.40
Static Pressure [Pa]
Air Volume [m
3
/s]
DF20 - 26 EC Backward Fan Curve
DF20
DF22
-
26
DF13 - 17 - EC Backward Fan Curve
DF20 - 26 - EC Backward Fan Curve
