Page 36
Throttle Hold
Page F2 (TH-HLD)
* This function enabled to stop the engine by pressing the button switch for
the models such as RC boats. (As known as “ENGINE CUT”)
* This can be used as an emergency brake while driving a model vehicle
by pressing the switch, trigger is disabled as long as the switch is de-
pressed.
* With engine-powered models, “THROTTLE HOLD” function enabled to set
the throttle slightly open to hold the steady engine idling. This will prevent
the engine from stopping during refueling on the pit stop.
1) First, assign TH-HLD to the switch wherever switch
location desired by using key assign function.
( page 44)
* The throttle hold function works only when the
TH-HLD switch is depressed.
2) Using the function select keys, move the cursor to
TH-HOLD.
3) Make sure that
u appears to the left of the percent-
age value, and then set the TH-HOLD percentage
by pressing the Inc.+ or Dec.- key.
* Setting range -160% to 140%
* Original setting 0
* When TH-HLD is ON, the servo is locked to the
preset position, regardless of the current trigger
position.
4) Setting INH/ACT for TH-HOLD
Move u to the right of TH-HOLD with the ENTER
key, and then select INH or ACT by pressing the
Inc.+ or Dec.- key.
* Ordinarily, select INH to use this function.
When ACT is selected, pressing the switch cancels
throttle hold.
5) Setting HOLD-3CH
Move u to the right of HOLD-3H with the ENTER
key, and then select the setting by pressing the Inc.+
or Dec.- key.
* This setting is effective only when 3CH-BRAKE
is active. (BR-MIX page 34)
6) Setting HOLD-4CH
Move u to the right of HOLD-4CH with the ENTER
key, and then select the setting by pressing the Inc.+
or Dec.- key.
* This setting is effective only when 4CH is se-
lected.
To Next Page
