Page 47
Switch / Trim Assignment
Page F3 ( -ASGN)
* Functions and trim settings (adjustments to function settings) can be freely
assigned to SW1-SW3, trimmers TRM1-TRM5, and the dial control on the
transmitter.
* Locations of switches and trimmers
[SW]
Key Assign Switch
* ON/OFF control of various functions can be assigned to SW1-SW3, making it easy to use those functions during
operation.
* Up to three functions (FUNC1-FUNC3) can be assigned to a single switch, allowing all of those functions to be
controlled at once.
* Functions originally assigned to switches at the factory
TRM1: Steering trim SW1: Starting position
TRM2: Throttle trim SW2: Anti-lock braking
TRM4: Dual rate SW3: Timer
TRM5: End point adjust, brake
When the function is turned
ON, character be displayed .
Function status is also
displayed in the constant
display area.
Here, LAP-T, INT-T, and
DWP-T can all be turned
ON/OFF together.
Up to three functions can
be assigned to a single
switch.
