The SPEED setting does not affect steering when the wheel positioning is
located within the shaded areas outside the POINTS.
Using the function select keys, move the cursor to [ST] in SPEED.
FORWARD SETTING
Make sure that the arrow appears to the right of FORWARD, and then set the
FORWARD value by pressing the Inc.+ or Dec.- key.
Setting range 0 to 100 (Default setting 0)
RETURN SETTING
Move arrow to RETURN with the ENTER key, and then set the RETURN
value by pressing the Inc.+ or Dec.- key.
Setting range 0 to 100 (Default setting 0)
POINT SETTING
Move the arrow to the right of POINT with the ENTER key, and then set the
POINT value by pressing the Inc.+ or Dec.- key.
Setting range 5% to 100% (Default setting 100%)
INH/ACT SPEED
To activate the SPEED function, select ACT, and to deactivate, select INH.
Using the ENTER key, move > to the right of SPEED.
Select INH or ACT by pressing the Inc.+ or Dec.- key.
NOTE
When driving a model vehicle, proper steering is vital, and excessive steering
is to be avoided at all times. The steering speed setting helps to limit exces-
sive steering, which will enable you to achieve smoother cornering.
It is advisable to use both Steering Speed & Exponential functions together
which enable you to achieve the best combination of steering operation.
This function slows down the steering servo speed during steering. Speed can
be set separately for steering movement say from neutral to certain point and
return directions. But note that actual steering operation is slower than in its set
speed of the servo, this function does not affect any.
1.
2.
3.
4.
5.
