- 15-
3. DESCRIPTION OF ROBOT STRUCTURE
3.1 Illustration
Phoenix350~450
Base
Compartment
Control Box
Crosswise
Compartment
Pneumatic
Compartmen
t
Headwork (EOAT)
(For model denotes “V” only)
Arm
Compartment
