8 Manual Operation
8.1 Screen Display
If there’s the icon ,just press the manual
key to start manual operation.
Normally free operation is abled,but ascend/descend/reach/retract in mould is restricted by
the mode setting.
Retract
Reach
01：L-Trace Male
Ascend
○
×
Descend
○
×
02：L-Tracee Female
Ascend
×
○
Descend
×
○
03：U-Trace Male
Ascend
○
×
Descend
×
○
04：U-Trace Female
Ascend
×
○
Descend
○
×
05：Second Male S&C
Ascend
○
×
Descend
○
×
06：Second Female S&C
Ascend
×
○
Descend
×
○
07：U-Trace Female-in
Ascend
×
○
Descend
○
×
08：U-Trace Male-in
Ascend
○
×
Descend
×
○
Manual
