- 5-

Unit：mm

2.2 Installation Dimensions

For the Machine Platen:

Remark: Dimensions shown in ( ) are for the telescopic version

CAUTION: Pay close attention to the gravity center during handling with a

fork-lift and sure to avoid from dropping.

Lifting Point

CAUTION

Prevent Swing Safety Screw

Please make sure screw to be locked up

when transportation and take out the

screw before operation.
