46
4.6 Adjustment of Moving Speeds
4.6.1 Speed Adjustment for Crosswise Forward and Backward
PROCEDURES:
(1) Turns the crosswise forward speed control valve for the adjustment of crosswise
forward moving speed.
(2) Turns the crosswise backward speed control valve for the adjustment of
crosswise backward moving speed.
(3) Turns clockwise for lowering speed, and in contract turns counter-clockwise for
faster speed.
(4) After proper adjustment is made, turns the locking nuts tightly.
Crosswise Forward
Speed Control Valve
Crosswise Backward
Speed Control Valve
To Next Page
