Manual correspondence list in the restrained items.
Both screw-in and screw-out limit are OFF.
When in non-descending status,the ascending
limit X1 is ON.
Reach in the mode of not ascending in the reach
position.
Retract in the mode of not ascending in the
retract position.
Both screw-in and screw-out limit are OFF.
When in non-ascending status, the ascending
limit X1 is OFF.
Reach in the mode of not descending in the
reach position.
Retract in the mode of not descending in the
retract position.
[Mould complete] is OFF in the screw-in side.
When middle plate is confirmed to use,[middle
plate] is OFF in the screw-in side.
Screw-in (Y3) or screw-out (Y4) output is ON.
Reach output (Y2) is OFF.
When in non-screw-out status, screw-in limit(X3)
is ON.
When screw-out standby,[mould complete] is
OFF.
When in non-screw-out status, but screw-out
limit(X4)is ON.
Sorption open (Y6)is OFF.
Sorption open (Y6) is ON.
