- 20-
Part List for Base Compartment of Poenix350~450
ITEM
DESCRIPTION
PART NO.
Q`TY
REMARK
1
Base Block
PC03A040
03A
1
2
Location Ring
PC03A070
1
3
Column
PC03A090
1
4
Location Pin
PI00A080
1
5
Arch
PC03A010
1
6
Tube Fitting, quick release
PET2001
1
7
Swing Axle
PC03A030
1
8
Swing Angle Adjustment Knob
PC03A060
1
9
Connector Block, swing cylinder
MBG5-PHS12
1
10
Swing Cylinder
YC320080
1
11
Swivel Shaft, swing cylinder
PC03A050
1
12
swing cylinder Base
PC03A020
13
Axle Bearing
MBG1-6007
2
14
Location Screw
PC03A080
1
