98
Additional Information for Alicat
CSA and ATEX Approved Devices
EEx nA IIC T4
Class I, Div. 2 Group A, B, C and D T4
24 Vdc, 0.800A max
Class I, Zone 2 AEx nA IIC T4
WARNINGS:
EXPLOSION HAZARD – DO NOT DISCONNECT WHILE
CIRCUIT IS LIVE UNLESS AREA IS KNOWN TO BE NON-
HAZARDOUS.
EXPLOSION HAZARD – SUBSTITUTION OF COMPONENTS
MAY IMPAIR SUITABILITY FOR CLASS I, DIVISION 2.
II 3 G
Alicat CSA / ATEX approved devices are equipped with either a locking
six pin industrial connector (IC), locking D-sub 15 pin connector (DB15) or
locking D-sub 9 pin connector (DB9). Please see page 94 to page 97
for the correct power and signal connections for each type of connector.
See the following page for special conditions regarding the use of
these units!
