AXU2CGB-E User Manual
40
/
57
www.alinx.com
USB_DATA1
PS_MIO57
A16
USB2.0 Data Bit1
USB_DATA2
PS_MIO54
F17
USB2.0 Data Bit2
USB_DATA3
PS_MIO59
E17
USB2.0 Data Bit3
USB_DATA4
PS_MIO60
C17
USB2.0 Data Bit4
USB_DATA5
PS_MIO61
D17
USB2.0 Data Bit5
USB_DATA6
PS_MIO62
A17
USB2.0 Data Bit6
USB_DATA7
PS_MIO63
E18
USB2.0 Data Bit7
USB_STP
PS_MIO58
F18
USB2.0 Stop Signal
USB_DIR
PS_MIO53
D16
USB2.0 Data Direction Signal
USB_CLK
PS_MIO52
G18
USB2.0 Clock Signal
USB_NXT
PS_MIO55
B16
USB2.0 Next Data Signal
USB_RESET_N
PS_MIO31
H16
USB2.0 Reset Signal
Part 3.5: Gigabit Ethernet Interface
There are 2 Gigabit Ethernet ports on the AXU2CGB-E carrier board, one
is connected to the PS end, and the other is connected to the PL end. The
GPHY chip uses JLSemi JL2121-N040I Ethernet GPHY chip to provide users
with network communication services. The Ethernet PHY chip on the PS side is
connected to the MIO interface of the BANK502 of the PS side of ZYNQ. The
Ethernet PHY chip on the PL side is connected to the IO of the BANK66. The
JL2121-N040I chip supports 10/100/1000 Mbps network transmission rate, and
communicates with the MAC layer of the ZU2CG system through the RGMII
interface. JL2121-N040I supports MDI/MDX adaptation, various speed
adaptation, Master/Slave adaptation, and MDIO bus for PHY register
management.
When the JL2121-N040I is powered on, it will detect the level status of
some specific IOs to determine its own operating mode. Table 3-5-1 describes
the default settings after the GPHY chip is powered on.
Configuration Pin
Instructions
Configuration value
RXD3_ADR0
RXC_ADR1
MDIO/MDC Mode PHYaddress
PHY Address 001
