Multi-Axis Coordinated Motion Instructions

  Rockwell Automation Publication MOTION-RM002H-EN-P-February 2018  379
Inputs
The following table explains the instruction inputs. The inputs may be field device
signals from input devices or derived from user logic.
Operand    Data Type  Format  Description
Path  PATH_DATA  Tag  See PATH_DATA Structure
Length  DINT  Immediate Tag  This input is immediate and indicates the length
of the PATH_DATA input.
Tip: Set the length to 1. Values greater than 1 are
reserved for future use.
Dynamics  DYNAMICS_DATA  Tag  See DYNAMICS_DATA Structure
Lock Position  REAL  Tag  Position on the Master Axis where a Slave should
start following the master after the move has
been initiated on the slave axis coordinate
system.
Tip: Lock Position is only valid when the MCPM
instruction is used in Master Driven Speed Control
mode.
Lock Direction  UINT32  Tag  Specifies the conditions when the Lock should be
activated.
Tip: Lock Direction is only valid when the MCPM
instruction is used in Master Driven Speed Control
mode.
PATH_DATA Structure
Operand  Scroll, List, or Check Box  Data Type  Default  Notes
Interpolation Type  List of Point-to-Point (0) Continuous
Path Linear (1)
DINT  0  Point-to-point move
2

Continuous Path Linear
See Interpolation Type related topics
below.
Position [X, Y, Z, Rx, Ry, Rz]  List of constant or variable  REAL [9] 1  0  [X,Y.Z] in Coordination Units,
[Rx, Ry, Rz] X-Y-Z fixed angle format in
degrees
Index 0: X
 1: Y
 2: Z
 3: Rx
 4: Ry
 5: Rz
 6: *
2

 7: *
2

 8: *
2

See Position related topics in the
following section.
