Program a velocity profile and jerk rate and tune an S-Curve Profile
Chapter 8
Rockwell Automation Publication MOTION-RM002H-EN-P-February 2018 555
If There Is Then Which Results In
NOT too much jerk Reduce the % of Time
Too much jerk Increase the % of Time
5. Repeat steps 3 and 4 until you have the desired balance between smoothness
and cycle time.
