Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019 23
Configure and Startup Chapter 2
Fault/Program Action Page
Configure the output state value for each individual channel of your module
when the controller’s mode changes to fault or program.
Figure 7 - Example of Fault/Program Action Page
Controls
Refresh Refresh the data on the page
Reset Module Reset the module to factory settings
Table 14 - Fault/Program Action Parameters
Parameter Definition
Output State During Fault/Program
Mode
Off, On, Hold
IMPORTANT Do not change the Output State During Fault/Program Mode values while the
module is online, regardless of whether it is through the Fault/Program Action
page, through controller tags, or with message instructions.
Changes take effect only after you cycle power to the module.
Table 13 - Module Info Parameters
Parameter Definition
