Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019 33
Configure Module Using Generic Profile Chapter 3
Tag Name Conventions
The module tag names use defined naming conventions. The conventions are as
follows:
Tag name examples = Module1:I.PowerFault
• Module1 = name of the module as assigned during module configuration
•I = tag type
The possible tag types are I (input) and O (output).
• PowerFault = tag function
In this case, PowerFault signifies that sensor power supply voltage is less
than 18V. For a list of tag functions available for the module, see
Description of Terms in Process Data Tables
on page 32.
OutputGroupPowerFaultEn Enables or disables the output group power fault reporting.
0 = Disable (default), 1 = Enable
OutputGroupFaultEn Enables or disables the output group fault when actuator power supply is unavailable.
0 = Disable (default), 1 = Enable
DOAutoRestartEn Enables or disables the digital out auto restart.
0 = Disable (default), 1 = Enable
Table 19 - Description of Terms in Process Data Tables
Parameter Description
