24 Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019
Chapter 2 Configure and Startup
Configuration Page
Configure the Fault Delay and Data Direction for each individual channel of
your module.
Figure 8 - Example of Configuration Page
Table 15 - Configuration Parameters
Parameter Definition
Fault Delay Set the fault delay from 0…255 ms. Default is 80 ms.
Data Direction Set whether the direction of data is input only, output only, or both input
and output. You cannot change the data direction when the module is
online.
Disable Web Server Select to disable the web server.
Enable Output Group Power Fault
Reporting
Select to enable reporting of power faults.
Enable Output Group Fault Select to enable output group fault when actuator power supply is
unavailable.
Enable Digital Out Auto Restart Select to enable the module to auto restart a digital output.
