Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019 7
Chapter 1
Module Information
About the Module
The ArmorBlock 16-channel configurable digital module offers easy handling of
I/O data in a higher-level bus system. It is suitable for use in machines and
installations with moderate I/O concentration.
A compact, fully sealed housing made of die-cast zinc helps to protect electronic
components from environmental factors. This makes the module ideal for direct
field service in tough industrial environments.
For connecting the network and I/O, the module uses the widely adopted M12
connector system; A-coded connectors for I/O signals and D-coded connectors
for network communication. For connecting power, the
1732E-16CFGM12M12LDR uses M12, L-coded connectors, while the
1732E-16CFGM12P5DR uses 7/8-inch connectors.
Module Features
The ArmorBlock 16-channel configurable digital module provides the following
features:
• Integrated switch
An integrated 2-port Ethernet switch enables the use of bus or star
network topologies. The implemented device level ring (DLR) protocol
enables the design of a highly accessible network infrastructure.
• Redundancy function
The module supports the device level ring (DLR) protocol for ring
topologies. If the connection is interrupted, the module immediately
switches to an alternative ring segment to ensure interruption-free
operation.
• Output Fault Values function
This function enables you to define the behavior of each output channel in
the event of interruption or loss of communication.
Topic Page
About the Module 7
Module Features 7
Module Overview 8
Before You Begin 8
