32 Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019
Chapter 3 Configure Module Using Generic Profile
Configuration Data
16-bit configuration data with diagnostics and padding byte, default I/O
mapping, assembly Instance 110.
Description of Process Data
Terms
The following table lists the definition for terms that are used in the process data
tables for the ArmorBlock 16-channel configurable digital module.
Parameter Datatype
CfgSize DINT
CfgIDNum DINT
Pt00FaultDelay…Pt15FaultDelay INT
Pt00Fault…Pt15Fault INT
Pt00FaultValue…Pt015FaultValue BIT
Pt00FaultMode…Pt15FaultMode BIT
MiscSettings INT
QuickConnectEn BIT
WebServerDisable BIT
OutputGroupPowerFaultEn BIT
OutputGroupFaultEn BIT
DOAutoRestartEn Bit
Pt00DataDirection…Pt15DataDirection INT
Pt00IOMapping…Pt15IOMapping INT
Table 19 - Description of Terms in Process Data Tables
Parameter Description
C0…C15 Refers to the status of the channel.
PowerFault Sensor power supply voltage is < 18V ±1V.
FieldPowerLow Output power supply voltage is < 18V ±1V.
InputGroupFault Sensor error
OutputGroupFault Output error
InternalFault Module error
Ptxx_xxInputShortCircuit Sensor short-circuit on ports P0…P7
PtxxOutputFault Output fault on channels C0…C15
PtxxFaultDelay Fault delay on channels C0…C15
PtxxFaultValue Fault value for channels C0…C15
PtxxDataDirection Direction of data for channels C0…C15
QuickConnectEn Enables or disables QuickConnect.
0 = Disable (default), 1 = Enable
WebServerDisable Enables or disables the web server.
0 = Enable (default), 1 = Disable
