Allen-Bradley ArmorBlock 1732E-16CFGM12M12LDR User Manual

Rockwell Automation Publication 1732E-UM001A-EN-P - December 2019 39
Appendix A
Interpret Status Indicators
Status Indicator Overview
See the following figure to identify the location of the status indicators.
Figure 12 - Status Indicators
Topic Page
Status Indicator Overview 39
Status Indicator Descriptions 40
MAC: XX-XX-XX-XX-XX-XX
MAC: XX-XX-XX-XX-XX-XX
Channel status indicators
1732E-16CFGM12M12LDR 1732E-16CFGM12P5DR
LNK1/LNK2 = EtherNet/IP connection status indicator
MS = Module status indicator
NS = Network status indicator
U
L
= Actuator power supply status indicator
U
S
= Sensor power supply status indicator
