Allen-Bradley LOGIX 5000 User Manual

Chapter 1
Process Control Instructions
152 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
CV2Oper REAL CV2 Operator-Manual value. CV2 is set
to this value when in Operator control
and Manual mode. If not Operator-
Manual mode, set CV2Oper to the
value of CV2 at the end of each
function block execution.
If value of CV2Oper < 0 or > 100, or <
CV2LLimit or > CV2HLimit when
CVManLimiting is TRUE, set unique
Status bit and limit value used for CV.
Valid = 0.0…100.0
Default = 0.0
CV3Oper REAL CV3 Operator-Manual value. CV3 is set
to this value when in Operator control
and Manual mode. If not Operator-
Manual mode, set CV3Oper to the
value of CV3 at the end of each
function block execution.
If value of CV3Oper < 0 or > 100, or <
CV3LLimit or > CV3HLimit when
CVManLimiting is TRUE, set unique
Status bit and limit value used for CV.
Valid = 0.0…100.0
Default = 0.0
CV1OverrideValue REAL CV1 Override value. CV1 set to this
value when in Override mode.
This value should correspond to a safe
state output of the loop.
If value of CV1OverrideValue < 0 or
>100, set unique Status bit and limit
value used for CV.
Valid = 0.0…100.0
Default = 0.0
CV2OverrideValue REAL CV2 Override value. CV2 set to this
value when in Override mode.
This value should correspond to a safe
state output of the loop.
If value of CV2OverrideValue < 0 or
>100, set unique Status bit and limit
value used for CV.
Valid = 0.0…100.0
Default = 0.0
CV3OverrideValue REAL CV3 Override value. CV3 set to this
value when in Override mode.
This value should correspond to a safe
state output of the loop.
If value of CV3OverrideValue < 0 or
>100, set unique Status bit and limit
value used for CV.
Valid = 0.0…100.0
Default = 0.0
