Chapter 1
Process Control Instructions
158 Rockwell Automation Publication 1756-RM006K-EN-P - November 2018
CV2Target REAL Target value for CV2. Valid = 0.0…100.0
Default = 0.0
CV3Target REAL Target value for CV3. Valid = 0.0…100.0
Default = 0.0
CV1WindupHIn BOOL CV1Windup high request. When TRUE,
CV1 will not be allowed to increase in
value. This signal will typically be the
CV1WindupHOut output from a
secondary loop.
Default = FALSE
CV2WindupHIn BOOL CV2Windup high request. When TRUE,
CV2 will not be allowed to increase in
value. This signal will typically be the
CV2WindupHOut output from a
secondary loop.
Default = FALSE
CV3WindupHIn BOOL CV3Windup high request. When TRUE,
CV3 will not be allowed to increase in
value. This signal will typically be the
CV3WindupHOut output from a
secondary loop.
Default = FALSE
CV1WindupLIn BOOL CV1 Windup low request. When TRUE,
CV1 will not be allowed to decrease in
value. This signal will typically be the
CV1WindupLOut output from a
secondary loop.
Default = FALSE
CV2WindupLIn BOOL CV2 Windup low request. When TRUE,
CV2 will not be allowed to decrease in
value. This signal will typically be the
CV2WindupLOut output from a
secondary loop.
Default = FALSE
CV3WindupLIn BOOL CV3 Windup low request. When TRUE,
CV3 will not be allowed to decrease in
value. This signal will typically be the
CV3WindupLOut output from a
secondary loop.
Default = FALSE
GainEUSpan BOOL CVxModelGain units can be
represented as EU or % of span. Set to
interpret ModelGain as EU, reset to
interpret ModelGain as % of Span.
Default = 0
CV1ProcessGainSign BOOL Used only for Autotuning. Sign of the
process gain (Delta PV/Delta CV1).
Set to indicate a negative process gain
(increase in output causes a decrease
in PV).
Reset to indicate a positive process
gain (increase in output causes an
increase in PV).
Default = FALSE
CV2ProcessGainSign BOOL Used only for Autotuning. Sign of the
process gain (Delta PV/Delta CV2).
Set to indicate a negative process gain
(increase in output causes a decrease
in PV).
Reset to indicate a positive process
gain (increase in output causes an
increase in PV).
Default = FALSE
