Allen-Bradley LOGIX 5000 User Manual

Process Control Instructions
Chapter 1
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 157
CV1HandFB REAL CV1 HandFeedback value. CV1 set to
this value when in Hand mode and
CV1HandFBFault is FALSE (good
health). This value would typically
come from the output of a field
mounted hand/auto station and
would be used to generate a bumpless
transfer out of Hand mode. If value of
CV1HandFB < 0 or > 100, set unique
Status bit and limit value used for CV1.
Valid = 0.0…100.0
Default = 0.0
CV2HandFB REAL CV2 HandFeedback value. CV2 set to
this value when in Hand mode and
CV2HandFBFault is FALSE (good
health). This value would typically
come from the output of a field
mounted hand/auto station and
would be used to generate a bumpless
transfer out of Hand mode. If value of
CV2HandFB < 0 or > 100, set unique
Status bit and limit value used for CV2.
Valid = 0.0…100.0
Default = 0.0
CV3HandFB REAL CV3 HandFeedback value. CV3 set to
this value when in Hand mode and
CV3HandFBFault is FALSE (good
health). This value would typically
come from the output of a field
mounted hand/auto station and
would be used to generate a bumpless
transfer out of Hand mode. If value of
CV3HandFB < 0 or > 100, set unique
Status bit and limit value used for CV3.
Valid = 0.0…100.0
Default = 0.0
CV1HandFBFault BOOL CV1HandFB value bad health
indicator. If the CV1HandFB value is
read from an analog input, then
CV1HandFBFault will normally be
controlled by the status of the analog
input channel. If CV1HandFBFault is
TRUE, it indicates an error on the input
module, set bit in Status.
FALSE = Good Health
Default = FALSE
CV2HandFBFault BOOL CV2HandFB value bad health
indicator. If the CV2HandFB value is
read from an analog input, then
CV2HandFBFault will normally be
controlled by the status of the analog
input channel. If CV2HandFBFault is
TRUE, it indicates an error on the input
module, set bit in Status.
FALSE = Good Health
Default = FALSE
CV3HANDFBFault BOOL CV3HandFB value bad health
indicator. If the CV3HandFB value is
read from an analog input, then
CV3HandFBFault will normally be
controlled by the status of the analog
input channel. If CV3HandFBFault is
TRUE, it indicates an error on the input
module, set bit in Status.
FALSE = Good Health
Default = FALSE
CV1Target REAL Target value for CV1. Valid = 0.0…100.0
Default = 0.0
