Process Control Instructions
Rockwell Automation Publication 1756-RM006K-EN-P - November 2018 171
CV1RespTCTunedM REAL The calculated value of the control
variable time constant in medium
response speed for CV1 after tuning
is completed.
CV2RespTCTunedM REAL The calculated value of the control
variable time constant in medium
response speed for CV2 after tuning
is completed.
CV3RespTCTunedM REAL The calculated value of the control
variable time constant in medium
response speed for CV3 after tuning
is completed.
CV1RespTCTunedF REAL The calculated value of the control
variable time constant in fast
response speed for CV1 after tuning
is completed.
CV2RespTCTunedF REAL The calculated value of the control
variable time constant in fast
response speed for CV2 after tuning
is completed.
CV3RespTCTunedF REAL The calculated value of the control
variable time constant in fast
response speed for CV3 after tuning
is completed.
AtuneCV1On BOOL Set True when auto tuning for CV1
has been initiated.
AtuneCV2On BOOL Set True when auto tuning for CV2
has been initiated.
AtuneCV3On BOOL Set True when auto tuning for CV3
has been initiated.
AtuneCV1Done BOOL Set True when auto tuning for CV1
has completed successfully.
AtuneCV2Done BOOL Set True when auto tuning for CV2
has completed successfully.
AtuneCV3Done BOOL Set True when auto tuning for CV3
has completed successfully.
AtuneCV1Aborted BOOL Set True when auto tuning for CV1
has been aborted by user or due to
errors that occurred during the auto
tuning operation.
AtuneCV2Aborted BOOL Set True when auto tuning for CV2
has been aborted by user or due to
errors that occurred during the auto
tuning operation.
AtuneCV3Aborted BOOL Set True when auto tuning for CV3
has been aborted by user or due to
errors that occurred during the auto
tuning operation.
AtuneCV1Status DINT Indicates the tuning status for CV1.
AtuneCV2Status DINT Indicates the tuning status for CV2.
AtuneCV3Status DINT Indicates the tuning status for CV3.
